| Product Attribute | Attribute Value |
|---|---|
| Accuracy | ±0.25 % |
| Features | Temperature Compensated |
| Function | Pressure |
| Maximum Pressure Measured | 300 (2068.43) PSI (kPa) |
| Measurement Range | 100 psi |
| Measurement Units | psi |
| Operating Temperature | -40 ~ 125 °C |
| Output | 0-100 mV (10V) |
| Output Type | Wheatstone Bridge |
| Package Type | Cylinder |
| Port Size, Gauge | Male - 1/8 (3.18) NPT In. (mm) |
| Port Style | Threaded |
| Pressure, Operating | 100 (689.48) PSI (kPa) |
| Series | |
| Supply Voltage | 15 VDC |
| Technology | Piezoelectric |
| Termination | Ribbon Cable |
| Type | Vented Gauge |
Overview
Honeywell's stainless steel 19C Vacuum Gage Series sensors were developed for pressure applications that involve measurement of hostile media in harsh environments compatible with 316 stainless steel. The special Vacuum Gage Series sensors are specifically designed for applications that can be exposed to vacuum. The 19C Series are calibrated and temperature compensated. They are available for use with either a constant voltage or current source. They feature a variety of pressure connections to allow use in a wide range of OEM (Original Equipment Manufacturer) equipment. The 19C Series sensors are rugged and reliable transducers for use in a wide variety of pressure sensing applications where corrosive liquids or gases are monitored.
Features:
Typical Applications:
